3D → 2D
Release-ready drawings, generated from your 3D model.
Draw produces complete GD&T drawing packages directly from your 3D CAD model — views, dimensioning, datums, tolerancing, and annotation — conforming to your company drawing standard and applicable ASME Y14.5 / ISO GPS conventions, and released only under your engineers' sign-off.
Drop your 3D model here
mount_bracket_r2.step8.4 MB · STEP
Drafting...Producing released drawings at
Process
From model to released drawing, in three steps.
01
Import the model
Native CAD or neutral formats, directly from SolidWorks, NX, CATIA, or Autodesk.
02
Draw generates the package
Views, dimensions, datums, tolerances, and notes, produced to your drawing standard and ASME Y14.5 / ISO GPS.
03
Your engineer signs off
Every drawing is reviewed and approved before it enters your release process.
Validated at DN Automotive
